Product Details
Basic Information
| Model | Dimensions (mm) | Weight (kg) | Working Temp. | Rel. Humidity | Power |
| PSK-2 | 240×28×120 | 3.0 | -10℃ ~ +45℃ | ≤90% (at +45℃) | <36W |
Description
This system retains all the functions of the original digital logging system while achieving bidirectional communication, allowing computer control of both the probe strings and the host unit. Functions such as sonic threshold, electrical logging gain, range, power supply, caliper extension/retraction, and depth correction can all be controlled via software.
Probe strings are freely assembled using single-core quick-connectors, enabling simultaneous multi-parameter measurement. All outputs are digital signals, unaffected by cable attenuation. Upon startup, the system automatically detects connected probes and identifies probe name, parameter values, recording point, curve colour, value range, units, and other information.
The logging curve display interface supports free conversion between physical quantities and curve values. The system features self-calibration for pre-logging verification and on-site three-point calibration, and is compatible with the full range of winch systems.
Specification
| Parameter | Value | Parameter | Value |
| Probe Power Supply | DC 200V, max. current 120mA | Input Signal | Power-line carrier, 200mV |
| Optical Encoder | Field-settable, default 250 pulses/rev | Sampling Interval | 1, 2, 5, 10, 20 cm (default 5 cm) |
| Depth Correction | -12.7 mm ~ +12.7 mm (per metre) | Logging Speed | ≤36 m/min |
| Communication Rate | 115200 bps | Data Range | 0 ~ 65535 |
